2-5747706-0 by te connectivity / amp brand
Image is representational - see mfr. specs
DATA SHEET

2-5747706-0

TE Connectivity / AMP Brand

9 Position D-Sub Receptacle, Female Sockets Connector .. see full description

RoHS Compliant
Tube Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-5747706-0
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The 2-5747706-0 is a 9-way 2-row front metal-shell D-sub Receptacle with gold-plated phosphor bronze contacts and retention 4-40 brass inserts. The Amplimite HD-20 series straight posted receptacle comes with black thermoplastic housing, tin-plated carbon steel shell and bright tin-plated solder tail. All receptacles are preloaded with size 20 DF posted socket contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308. UL94V-0 Flammability rating Vertical PCB mounting orientation Applications Industrial, Computers & Computer Peripherals
Product Highlights:
  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock
Search Keywords:
257477060
IN STOCK: 10
Can Ship immediately
Buy all 10 in-stock or the regular minimum order quantity of 17
Stock lot only:
10
Minimum Order Quantity:
17
Multiple:
17
Factory Lead-Time
2 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$4.213
$4.213
17
$3.830
$65.110
51
$3.780
$192.780
102
$3.710
$378.420
255
$3.610
$920.550
510
$3.570
$1,820.700
1,003
$3.560
$3,570.680
2,516
$3.550
$8,931.800
5,015 +
$3.540
$17,753.100
