3-1827233-6 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

3-1827233-6

TE Connectivity / AMP Brand

Stacking Board Connector - Free Height - FSI Series - 440 Contacts - Plug - 0.5 mm - Surface Mount. .. see full description

RoHS Compliant
TRAY Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827233-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
18
Package Type:
TRAY
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
PL
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
440
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C
The 3-1827233-6 is a 440-way 4-row 0.5mm Free Height Vertical Plug with gold-plated copper alloy contacts and surface mount termination. This FH series connector comes with black high temperature thermoplastic housing and tin-plated solder tail, designed for parallel board to board stacking applications that require high density. The 0.5mm FH product is specified by the PICMG COM Express standard as the module to carrier card interface.
Product Highlights:
  • Plug
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 440
  • In-Line Contact Layout
Search Keywords:
318272336
IN STOCK: 171
Can Ship immediately
On Order:
648   can ship 11/4/26
Factory Lead-Time
23 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$71.75
$71.75
5
$47.49
$237.45
18
$46.10
$829.80
36
$45.63
$1,642.68
54
$45.17
$2,439.18
108
$44.29
$4,783.32
252 +
$43.96
$11,077.92
Supplier's Standard Package
Product Changes
PDF PCN - 01-Aug-2015 - MANUFACTURING LOCATION CHANGE
PDF PCN - 27-Jul-2020 - CANCELLATION:CHANGE SOLDER TAIL PLATING FROM TIN TO GOLD FLASH
PDF PCN - 01-Aug-2015 - PART NUMBERS WILL BE TRANSFERRED FROM TE JAPAN PLANT TO TE QINGDAO PLANT, CHINA
PDF PCN - 31-Jan-2017 - 0.5FH, VERSION ALIGNMENT AND LOGO CHANGE ON HOUSING
PDF PCN - 31-Jan-2017 - 0.5FH, VERSION ALIGNMENT AND LOGO CHANGE ON HOUSING
PDF PCN - 13-Apr-2022 - Process Change Notification
PDF PCN - 25-Oct-2021 - MANUFACTURING LOCATION CHANGE
PDF PCN - 24-Aug-2020 - CANCEL PCN E-20-000066-C THAT IS A CANCELLATION PCN
PDF PCN - 27-Sep-2022 - MANUFACTURING LOCATION CHANGE
PDF PCN - 25-Aug-2021 - ADD MATED CONDITION INFO IN THE DRAWINGS
PDF PCN - 01-Sep-2017 - MANUFACTURING LOCATION CHANGE
PDF PCN - 01-Mar-2018 - CANCEL PCN P-18-015503
PDF PCN - 15-Aug-2018 - MANUFACTURING LOCATION CHANGE
PDF PCN - 19-Jun-2017 - CANCEL PREVIOUS PCN P-17-014467 MANUFACTURING LOCATION CHANGE
PDF PCN - 15-Aug-2018 - MANUFACTURING LOCATION CHANGE
PDF PCN - 19-Jun-2017 - CANCEL PREVIOUS PCN P-17-014467 - MANUFACTURING LOCATION CHANGE
PDF PCN - 19-Jul-2016 - THE DRAWINGS FOR THE LISTED PART NUMBERS HAVE BEEN MODIFIED-0.5FH, 440POS, CAP
PDF PCN - 15-Aug-2018 - MANUFACTURING LOCATION CHANGE
PDF PCN - 30-Aug-2020 - CANCEL PCN E-20-000066-C THAT IS A CANCELLATION PCN
PDF PCN - 19-Jul-2016 - THE DRAWINGS FOR THE LISTED PART NUMBERS HAVE BEEN MODIFIED
PDF PCN - 10-Jul-2020 - PRODUCT IMPROVEMENT - CHANGE SOLDER TAIL PLATING
PDF PCN - 04-Sep-2017 - 0.5FH PLUG 5H
PDF PCN - 01-Sep-2017 - MANUFACTURING LOCATION CHANGE
PDF PCN - 04-Sep-2017 - 0.5FH PLUG 5H
PDF Product Change Notification
