Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
350923-6
RoHS:
Yes
HTS:
8538908140
COO:
CN
ECCN:
EAR99
Supplier Standard Pack
2500
Package Type:
Reel
Contact Type:
Power
Gender:
SKT
Contact Size:
N/A
Wire Size:
10-12 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Gold over Nickel
Maximum Current Rating:
19 A
Termination Method:
Crimp
350923-6 is a socket contact designed for use in the Universal MATE-N-LOK connector system, part of TE Connectivity's Soft Shell Pin and Socket Connectors family. This contact features phosphor bronze construction with select gold plating for reliable electrical performance and corrosion resistance. It is designed for wire sizes ranging from 20-14 AWG (0.5-2.0 mm²) or 12-10 AWG (3.0-5.0 mm²), with an insulation diameter range of 0.130-0.200 inches (3.30-5.08 mm). The contact has a pin length dimension of 0.780 inches (20.17 mm) and socket length of 0.781 inches (19.81 mm). These contacts are commonly used in power circuit applications for home appliances, particularly gas appliances, where secure wire-to-board connections are required.
Product Highlights:
- Contact
- Universal MATE-N-LOK
- Not CompactPCI
- Contact Type = Socket
- Wire Range = 3.00-6.00² [12-10] mm [AWG]
Search Keywords:
3509236
Different packaging options available. See Alternatives
IN STOCK:
8,516
Can Ship immediately
Minimum Order Quantity:
500
Factory Lead-Time
31 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
500
$0.4719
$235.9500
1,000
$0.4622
$462.2000
2,500
$0.4553
$1,138.2500
5,000
$0.4426
$2,213.0000
7,500
$0.4404
$3,303.0000
10,000
$0.4382
$4,382.0000
15,000
$0.4360
$6,540.0000
25,000
+
$0.4338
$10,845.0000
Product Guides
Accessories
58530-1
Crimp Tool - Ratchet - AMP Universal MATE-N-LOK 12 to 10 AWG Contacts - Te Connectivity / ...
58530-2
PROCRIMPER DIE
1579001-3
DIE UMNL 4-5MM2
539972-1
Extraction Tool for Universal MATE-N-LOK; Socket Ø1.5; TYPE II, III+; CI-2, -3, -H; Econos ...
9-1579007-5
Extraction Tool for Universal MATE-N-LOK Contacts - only with Housing contact cavity Ø 3.5 ...
455830-1
Insertion Tool for Universal MATE-N-LOK; Commercial MATE-N-LOK; Mini-Universal MATE-N-LOK
