3-644893-6 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

3-644893-6

TE Connectivity / AMP Brand

06P CST100 SHRD HDR ASSY LF .. see full description

RoHS Compliant
BAG Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-644893-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
PCB Mount Alignment:
With
Operating Voltage:
250 VAC
Connector System:
Wire-to-Board
Mating Retention Type:
Friction Lock
Housing Material:
Polyester - GF
PCB Mount Orientation:
Vertical
PCB Contact Termination Area Plating Material Thickness:
150 – 250 µin, 3.81 – 6.35 µm
Termination Method to Printed Circuit Board:
Through Hole - Solder
Contact Mating Area Plating Material:
Tin
Termination Post & Tail Length:
.14 in, 3.56 mm
Contact Underplating Material:
Nickel
Agency/Standard:
CSA , UL
Mating Square Post Dimension:
.025 in, .64 mm
Mating Retention:
With
Number of Rows:
1
PCB Thickness (Recommended):
.063 in, 1.6 mm
PCB Connector Assembly Type:
PCB Mount Header
PCB Mount Retention Type:
Tab
Contact Shape & Form:
Square
Contact Type:
Pin
Contact Base Material:
Copper Alloy
Mating Alignment Type:
Polarization
Circuit Application:
Signal
Contact Current Rating (Max):
4 A
Connector & Contact Terminates To:
Printed Circuit Board
UL Flammability Rating:
UL 94V-0
Connector Height:
.41 in, 10.41 mm
Number of Positions:
6
Contact Underplating Material Thickness:
50 µin, 1.27 µm
Contact Mating Area Plating Material Thickness:
150 – 250 µin, 3.81 – 6.35 µm
Connector Length:
.784 in, 19.91 mm
PCB Contact Termination Area Plating Material:
Tin
PCB Mount Retention:
With
Centerline (Pitch):
.1 in, 2.54 mm
Mating Alignment:
With
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
PCB Mount Alignment Type:
Peg
Contact Mating Area Length:
.28 in, 7.11 mm
Square Termination Post & Tail Dimension:
.025 in, .64 mm
Connector Mounting Type:
Board Mount
Packaging Quantity:
1
Contact Layout:
Inline
Panel Mount Feature:
Without
PCB Contact Termination Area Plating Material Finish:
Matte
Sealable:
No
Contact Mating Area Plating Material Finish:
Bright
Packaging Type:
Package
Approved Standards:
CSA LR7189 , UL E28476
Primary Product Color:
Black
Header Type:
Fully Shrouded
The TE Connectivity / AMP BRAND part 3-644893-6 is a 06P CST100 SHRD HDR ASSY LF connector assembly. This high-quality connector features a compact size and is designed for easy installation. Perfect for a variety of applications, this connector ensures reliable and secure connections.
Search Keywords:
36448936
IN STOCK: 4,956
Can Ship immediately
MOQ for In Stock Qty:
25
MOQ for out of Stock Qty:
1375
Factory Lead-Time
14 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
25
$2.714
$67.850
250
$2.707
$676.750
500
$2.701
$1,350.500
1,000
$2.694
$2,694.000
1,375
$2.687
$3,694.625
2,750
$1.423
$3,913.250
4,125
$1.001
$4,129.125
5,500 +
$0.981
$5,395.500
