5226978-3 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

5226978-3

TE Connectivity / AMP Brand

RTANG JK W/FLANGES, BNC PCB .. see full description

RoHS Compliant
TUBE Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5226978-3
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
TUBE
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
N/A
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
29.21 x 35.56 x 15.88 mm
Part number 5226978-3 is a RTANG JK W/FLANGES, BNC PCB connector by TE Connectivity / AMP Brand. This high-quality connector is designed for use in printed circuit boards and features a BNC interface, making it ideal for applications requiring reliable signal transmission. The compact size and included flanges ensure easy installation and secure attachment. Trust TE Connectivity / AMP Brand for durable and efficient connectivity solutions.
Product Highlights:
  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Right Angle
Search Keywords:
52269783
IN STOCK: 0
On Order:
507   can ship 9/21/26
Minimum Order Quantity:
17
Multiple:
17
Factory Lead-Time
36 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
17
$12.36
$210.12
34
$11.81
$401.54
51
$11.78
$600.78
102
$11.30
$1,152.60
255
$10.84
$2,764.20
510
$8.31
$4,238.10
1,003 +
$7.02
$7,041.06
Supplier's Standard Package
