5227161-3 by te connectivity / amp brand
Image is representational - see mfr. specs
DATA SHEET

5227161-3

TE Connectivity / AMP Brand

BNC Connector - Jack - Female Socket - 50 Ohms - 4 GHz - 500V - Solder Contact and Shield Termination - Panel Mount, Through Hole, Right Angle. .. see full description

RoHS Compliant
Tube Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5227161-3
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
14.76 x 34.93 x 15.88 mm
The 5227161-3 from TE Connectivity / AMP Brand is a white through-hole BNC Right Angle Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated phosphor bronze centre contact and a polymethylpentene insulator.
Product Highlights:
  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • Not Stacked
Search Keywords:
52271613
IN STOCK: 1,742
Ships today, if you order in
Minimum Order Quantity:
35
Multiple:
35
Factory Lead-Time
15 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
35
$2.40
$84.00
70
$2.21
$154.70
280
$2.13
$596.40
525
$2.12
$1,113.00
1,015
$2.11
$2,141.65
2,520
$1.88
$4,737.60
5,005
$1.85
$9,259.25
7,525 +
$1.82
$13,695.50
