DRB16-60SAE-L018 by te connectivity / deutsch automotive
Image is representational - see mfr. specs
DATA SHEET

DRB16-60SAE-L018

TE Connectivity / Deutsch Automotive

PLG, 60P, BLK, E, CAP, A

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DRB16-60SAE-L018
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting Feature:
Without
Circuit Application:
Power & Signal
Connector Mounting Type:
Bulkhead , Cable Mount (Free-Hanging) , Panel Mount
Operating Voltage:
250 VAC
Connector Code:
A
Contact Current Rating (Max):
13 A, 7.5 A
Degree of Protection:
IP68 , IP6K9K
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Connector & Housing Type:
Housing for female terminals
Primary Product Color:
Black
Cable Exit Angle:
180 °
Serviceable:
Yes
Number of Rows:
5
Height:
2.606 in, 66.19 mm
Connector System:
Wire-to-Wire
Body Material:
PA GF
Primary Locking Feature:
Integrated in Housing
Polarized:
Yes
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Terminal Position Assurance:
Yes
Connector Position Assurance Capable:
No
Row-to-Row Spacing:
.275 in, .3 in, 6.99 mm, 7.62 mm
Agency/Standard:
SAE J2030
Operating Temperature (Max):
125 °C, 257 °F
Centerline (Pitch):
.15 in, .175 in, 3.81 mm, 4.45 mm
Number of Positions:
60
Width:
2.606 in, 66.19 mm
Blank Cavity Position:
0
Mating Pin Diameter:
.04 in, .0625 in, 1.02 mm, 1.59 mm
Hybrid Connector:
Yes
Packaging Method:
Box
Length:
1.406 in, 35.71 mm
Strain Relief:
Yes
Packaging Quantity:
36
Sealable:
Yes
This TE Connectivity / Deutsch Automotive part DRB16-60SAE-L018 is a high-quality 60-pin PLG (plug) connector in black color, with E type termination and a protective cap for added durability and performance in automotive applications.
Search Keywords:
DRB1660SAEL018
IN STOCK: 132
Can Ship immediately
Minimum Order Quantity:
5
Factory Lead-Time
13 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$13.33
$66.65
10
$13.16
$131.60
25
$12.89
$322.25
50
$12.63
$631.50
100
$12.50
$1,250.00
250
$12.47
$3,117.50
500 +
$12.44
$6,220.00
