DRC16-40SE by te connectivity / deutsch automotive
Image is representational - see mfr. specs
DATA SHEET

DRC16-40SE

TE Connectivity / Deutsch Automotive

PLG, 40P, BLK, E

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DRC16-40SE
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Connector Mounting Type:
Cable Mount (Free-Hanging)
Length:
1.597 in, 40.56 mm
Strain Relief:
Add By Accessory
Polarized:
Yes
Degree of Protection:
IP68 , IP6K9K
Serviceable:
Yes
Primary Product Color:
Black
Connector Position Assurance Capable:
No
Cable Exit Angle:
180 °
Connector & Housing Type:
Housing for female terminals
Hybrid Connector:
No
Packaging Method:
Box
Centerline (Pitch):
.216 in, 5.49 mm
Connector System:
Wire-to-Wire
Sealable:
Yes
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Mating Pin Diameter:
.0625 in, 1.59 mm
Mounting Feature:
Without
Row-to-Row Spacing:
.216 in, 5.49 mm
Height:
1.202 in, 30.53 mm
UL Flammability Rating:
20mm Flame Test per Standard UL-94
Number of Positions:
40
Terminal Position Assurance:
No
Blank Cavity Position:
0
Primary Locking Feature:
Contact Retainer
Body Material:
PPS GF
Operating Temperature (Max):
125 °C, 257 °F
Packaging Quantity:
125
Agency/Standard:
SAE J2030
Operating Voltage:
250 VAC
Contact Current Rating (Max):
13 A
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Circuit Application:
Power & Signal
Number of Rows:
4
Width:
2.868 in, 72.85 mm
PLG, 40P, BLK, E
Search Keywords:
DRC1640SE
IN STOCK: 66
Ships today, if you order in
Factory Lead-Time
13 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$30.07
$30.07
5
$28.84
$144.20
10
$24.67
$246.70
25
$22.67
$566.75
50
$21.59
$1,079.50
100
$20.56
$2,056.00
250 +
$18.87
$4,717.50
