DT04-12PA-P075 by te connectivity / deutsch automotive
Image is representational - see manufacturer specifications
DATA SHEET

DT04-12PA-P075

TE Connectivity / Deutsch Automotive

REC, 12P, GRY, BUSBAR 3X4, NICKEL, A .. see full description

RoHS Compliant
Pack Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT04-12PA-P075
RoHS:
Yes
HTS:
8536698000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Circuit Application:
Power & Signal
Connector Code:
A
Degree of Protection:
IP68 , IP6K9K
Primary Locking Feature:
Integrated in Housing
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Packaging Method:
Box
Number of Positions:
12
Strain Relief:
Add By Accessory
Terminal Position Assurance:
Yes
Centerline (Pitch):
.359 in, 9.12 mm
Connector & Contact Terminates To:
Bus Bar , Wire & Cable
Length:
2.043 in, 51.89 mm
Hybrid Connector:
No
Connector Mounting Type:
Cable Mount (Free-Hanging) , Fixing Screw
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Height:
.876 in, 22.25 mm
Agency/Standard:
SAE J2030
Mounting Feature:
With
Connector Position Assurance Capable:
No
Mating Pin Diameter:
.0625 in, 1.59 mm
Cable Exit Angle:
180 °
Operating Temperature (Max):
125 °C, 257 °F
Connector & Housing Type:
Housing for Male Terminals
Packaging Quantity:
250
Polarized:
Yes
Row-to-Row Spacing:
.175 in, 4.45 mm
Primary Product Color:
Gray
Connector System:
Bus Bar-to-Wire
Serviceable:
Yes
Sealable:
Yes
Width:
1.597 in, 40.56 mm
Contact Current Rating (Max):
13 A
Number of Rows:
2
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Operating Voltage:
250 VAC
Body Material:
PA GF
Blank Cavity Position:
0
The TE Connectivity / Deutsch Automotive part DT04-12PA-P075 is a reliable and efficient connector designed for automotive applications. It features a 12-pin configuration and a gray color, making it easy to identify and connect properly. The connector uses a busbar 3x4 design, providing excellent conductivity and minimizing the risk of electrical failures. The nickel-plated construction ensures durability and corrosion resistance, making it suitable for use in various environments and conditions. With its REC (Rectangular) design, this connector offers a secure and reliable electrical connection.
Search Keywords:
DT0412PAP075
IN STOCK: 516
Can Ship immediately
Minimum Order Quantity:
5
Factory Lead-Time
13 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$10.76
$53.80
25
$9.24
$231.00
50
$9.15
$457.50
100
$9.06
$906.00
250
$8.44
$2,110.00
500
$8.42
$4,210.00
1,000 +
$8.40
$8,400.00
