D369-P66-NP0 by te connectivity / deutsch
Image is representational - see mfr. specs
DATA SHEET

D369-P66-NP0

TE Connectivity / Deutsch

369 6 WAY PLUG, NO CONTACTS, PIN .. see full description

RoHS Compliant
Bag Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch
Part No:
D369-P66-NP0
RoHS:
Yes
HTS:
8538906000
COO:
GB
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Shell Material:
Composite
Centerline (Pitch):
.1 in, 2.54 mm
Number of Positions:
6
Circuit Application:
Signal
Termination Method to Wire & Cable:
Crimp
Rear Grommet:
With
Contact Transmits (Typical):
Signal
Contact Retention:
With
Seal Color:
Natural
Connection Type:
Connector Assembly
Number of Columns:
3
Product Type:
Connector
Seal Material:
Fluorosilicone
Interfacial Seal:
With
Keying:
N
Mating Alignment:
With
Panel Gasket:
No
Accepts Wire Insulation Diameter Range:
.028 – .054 in, .71 – 1.37 mm
Fluid Resistance:
EN2591-315
Operating Temperature Range:
-55 – 175 °C, -67 – 347 °F
Seal Type:
Triple-Seal
Connector Style:
Plug
Cable Exit Angle:
180 °
Number of Rows:
2
Contact Type:
Pin
Material:
Composite
Shielded:
No
Sealable:
Yes
Housing Color:
Black
Operating Voltage:
1500 VAC, 1000 VDC
Size 22D Contact Quantity:
6
Mating Retention Type:
Button Latch
Fluid Type:
EN2591-317
Row-to-Row Spacing:
.1 in, 2.54 mm
Housing Material:
Composite
Strain Relief:
Without
Mating Alignment Type:
Keyed
Connector System:
Wire-to-Wire
Shell Size:
6
Number of Cavities:
6
Mating Retention:
With
For Use With:
Shell Size 6
The TE Connectivity/DEUTSCH part D369-P66-NP0 is a 369 series 6-way plug with no contacts. It features a pin configuration and is perfect for applications that require secure and reliable connections. This plug is compatible with other components in the 369 series and offers easy installation and removal. Please note that contacts are not included with this plug.
Search Keywords:
D369P66NP0
IN STOCK: 987
Can Ship immediately
Factory Lead-Time
33 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$29.04
$29.04
5
$28.08
$140.40
10
$25.59
$255.90
25
$23.95
$598.75
50
$22.46
$1,123.00
100
$20.45
$2,045.00
250 +
$20.04
$5,010.00
Please Note: Tariffs may apply for U.S. shipments
