D369-R33-BS1 by te connectivity / deutsch
Image is representational - see mfr. specs
DATA SHEET

D369-R33-BS1

TE Connectivity / Deutsch

369 3 WAY REC, CRIMP, SKT .. see full description

RoHS Compliant
Pack Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch
Part No:
D369-R33-BS1
RoHS:
Yes
HTS:
8536698000
COO:
GB
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Rear Grommet:
With
Shell Size:
3
Connector Style:
Receptacle
Cable Exit Angle:
180 °
Product Type:
Connector
Contact Size:
22
Housing Color:
Blue
Size 22D Contact Quantity:
3
Number of Rows:
1
Shielded:
No
Accepts Wire Insulation Diameter Range:
.028 – .054 in, .71 – 1.37 mm
Circuit Application:
Signal
Panel Gasket:
No
Material:
Composite
Mating Alignment Type:
Keyed
Contact Style:
Crimp
Connection Type:
Connector Assembly
Number of Positions:
3
Seal Material:
Fluorosilicone
Strain Relief:
Without
Mating Retention:
With
Fluid Type:
EN2591-317
Keying:
B
Fluid Resistance:
EN2591-315
Operating Temperature Range:
-55 – 175 °C, -67 – 347 °F
Packaging Method:
Package
Seal Type:
Triple-Seal
Contact Transmits (Typical):
Signal
Contact Retention:
With
Packaging Quantity:
1
Shell Material:
Composite
Sealable:
Yes
Number of Cavities:
3
Centerline (Pitch):
.1 in, 2.54 mm
Mating Retention Type:
Button Latch
Row-to-Row Spacing:
.1 in, 2.54 mm
Operating Voltage:
1500 VAC, 1000 VDC
Seal Color:
Natural
Interfacial Seal:
With
Number of Columns:
3
Contact Plating Material:
Gold
Termination Method to Wire & Cable:
Crimp
Contact Type:
Socket
Contact Current Rating (Max):
5 A
Connector System:
Wire-to-Wire
For Use With:
Shell Size 3
Housing Material:
Composite
Lattice Contact Mating Area Plating Material:
Gold
The TE Connectivity/DEUTSCH D369-R33-BS1 is a 3-way rectangular connector receptacle designed for reliable performance in demanding environments. This connector features a secure crimp socket configuration, ensuring robust and stable electrical connections. Engineered to withstand harsh conditions, it is ideal for use in a variety of applications, including automotive, aerospace, and industrial machinery, where durability and precision are paramount. The connector is part of the reputable 369 series, known for its superior quality and versatile connectivity solutions. Whether you are integrating complex systems or managing maintenance tasks, this TE Connectivity/DEUTSCH connector provides an excellent balance of performance and reliability.
Search Keywords:
D369R33BS1
IN STOCK: 130
Ships today, if you order in
MOQ for out of Stock Qty:
77
Factory Lead-Time
33 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$60.51
$60.51
25
$52.18
$1,304.50
50
$52.05
$2,602.50
77
$51.92
$3,997.84
154
$34.79
$5,357.66
231
$34.70
$8,015.70
308 +
$27.49
$8,466.92
Please Note: Tariffs may apply for U.S. shipments
