IM03JR by te connectivity / p-b brand
Image is representational - see mfr. specs
DATA SHEET

IM03JR

TE Connectivity / P&B Brand

Signal Relay 5VDC 2A DPDT(10x6x5.65)mm SMD Automotive .. see full description

RoHS Compliant
Reel Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
IM03JR
Alias/AKA:
1-1462037-6
RoHS:
Yes
HTS:
8536410030
COO:
PT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
10 x 6 x 5.7 mm
Termination Style:
J Legs
Coil Current:
28.1 mA
Contact Form:
2 Form C
The TE Connectivity / P&B Brand part IM03JR is a compact and reliable signal relay designed for automotive applications. With a small size of 10x6x5.65mm, this relay provides a compact solution for space-constrained automotive electronics systems.Operating at a voltage of 5VDC, this relay can handle a current of up to 2A, making it suitable for a wide range of automotive signal switching applications. The DPDT (Double Pole Double Throw) configuration allows for versatile and flexible signal routing.Designed for surface mount installation, this relay offers a convenient and space-saving solution for automotive electronics assembly. Its SMD (Surface Mount Device) technology ensures high reliability and secure connections.With its automotive-grade quality and robust construction, the IM03JR signal relay from TE Connectivity / P&B Brand is an excellent choice for automotive applications that require high-performance signal switching in a compact package.
Product Highlights:
  • IM Relay Series
  • DC Actuating System
  • Input Voltage = 5 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.
Search Keywords:
IM03JR
IN STOCK: 14,201
Ships today, if you order in
Minimum Order Quantity:
100
Factory Lead-Time
26 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$2.194
$219.400
250
$2.130
$532.500
500
$2.109
$1,054.500
1,000
$2.088
$2,088.000
3,000
$2.077
$6,231.000
5,000
$2.067
$10,335.000
8,000
$2.057
$16,456.000
10,000 +
$2.046
$20,460.000
Suppliers Standard Package
Please Note: Tariffs may apply for U.S. shipments
