IMB03CGR by te connectivity / p-b brand
Image is representational - see mfr. specs
DATA SHEET

IMB03CGR

TE Connectivity / P&B Brand

Signal Relay 5VDC 2A SPST-NO(10x7.5x5.65)mm SMD .. see full description

RoHS Compliant
Reel Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
IMB03CGR
Alias/AKA:
1462041-7
RoHS:
Yes
HTS:
8536410020
COO:
PT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
10 x 6 x 5.7 mm
Termination Style:
Gull Wing
Coil Current:
28.1 mA
Contact Form:
1 Form A
The TE Connectivity / P&B Brand part IMB03CGR is a reliable and high-performance signal relay. With a 5VDC coil voltage and a 2A switching current, it is capable of handling various electronic signals with ease. This surface mount device (SMD) has a compact size of 10x7.5x5.65mm, making it ideal for space-constrained applications. The SPST-NO configuration ensures that it can efficiently control and switch signals in a single-pole, single-throw manner. Overall, the IMB03CGR offers excellent performance, reliability, and compactness, making it an ideal choice for a wide range of electronic applications.
Search Keywords:
IMB03CGR
IN STOCK: 1,645
Can Ship immediately
MOQ for In Stock Qty:
100
MOQ for out of Stock Qty:
500
Factory Lead-Time
26 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$2.59
$259.00
250
$2.54
$635.00
500
$2.51
$1,255.00
1,000
$2.49
$2,490.00
1,500 +
$2.48
$3,720.00
Suppliers Standard Package
