T81N5D312-24 by te connectivity / p-b brand
Image is representational - see mfr. specs
DATA SHEET

T81N5D312-24

TE Connectivity / P&B Brand

The T81N5D312-24 is a signal PCB relay featuring a 1 Form C contact arrangement and a 24VDC standard coil. .. see full description

RoHS Compliant
Tube Packaging
Accessories
Discontinued & Replaced
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T81N5D312-24
Alias/AKA:
7-1393779-2
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPDT
Maximum Current Rating:
1 A
Mounting:
Through Hole
Operating Temperature:
-30 to 60 °C
Dimension:
15.4 x 10.9 x 11.7 mm
Termination Style:
PC Pin
Coil Current:
18.75 mA
Contact Form:
1 Form C
Life Cycle:
Discontinued & Replaced
The T81N5D312-24 is a T81 series signal PCB relay designed for through-hole mounting. It operates with a 24VDC standard coil that consumes 450mW and has a coil resistance of 1280 Ω. The relay features a 1 Form C (CO) contact configuration with gold overlay silver palladium alloy contacts, rated for 1A at 120VAC or 24VDC. With high dielectric strength and a wash-tight case, this component is well-suited for a variety of applications including audio communications circuits, logic and process control, and office automation.
Product Highlights:
  • T81N Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 1 Amps.
Search Keywords:
T81N5D31224
  This product is discontinued, but still in stock
IN STOCK: 14
Can Ship immediately
Buy all 14 in-stock or the regular minimum order quantity of 75
Stock lot only:
14
Minimum Order Quantity:
75
Multiple:
25
Price (USD)
Quantity
Unit Price
Ext. Price
1
$2.519
$2.519
75
$2.290
$171.750
150
$2.250
$337.500
300
$2.220
$666.000
600 +
$2.160
$1,296.000
Please Note: Tariffs may apply for U.S. shipments
RECOMMENDED REPLACEMENT
IM07TS
