T92S7A22-24 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
DATA SHEET

T92S7A22-24

TE Connectivity / P&B Brand

High Power PCB Relay - 2 form A (2 NO) - 24VAC Coil - 30A Contact Rating - 600VAC Switching - Sealed Plastic Case - 0.250" Quick Connect. .. see full description

RoHS Compliant
BAG Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T92S7A22-24
Alias/AKA:
1393212-4
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
BAG
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPST-NO
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 65 °C
The T92S7A22-24 from TE Connectivity / P&B Brand is chassis mount high power PCB relay with 2 form A (2 NO) contact arrangement, 24VAC coil voltage and 36.6 Ohms coil resistance. This sealed plastic case relay has silver cadmium oxide (AgCdO) contacts, 30A contact current rating, 600VAC maximum switching voltage and 0.250" (6.3mm) quick connect termination. Operating temperature range is from -55°C to 65°C.
Product Highlights:
  • T92 Series
  • Contact Arrangement = 2 Form A, DPST-NO, 2 N/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC
Search Keywords:
T92S7A2224
IN STOCK: 0
On Order:
1,320   can ship 9/28/26
Factory Lead-Time
23 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$27.36
$27.36
5
$22.55
$112.75
10
$22.49
$224.90
30
$22.11
$663.30
60
$22.05
$1,323.00
120
$22.00
$2,640.00
270 +
$21.94
$5,923.80
Supplier's Standard Package
