T9GV1L14-12 by te connectivity / p-b brand
Image is representational - see mfr. specs
DATA SHEET

T9GV1L14-12

TE Connectivity / P&B Brand

Power Relay SPST-NO 480VAC 12VDC PC Pins Through Hole Tube .. see full description

RoHS Compliant
Tube Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T9GV1L14-12
Alias/AKA:
1558661-3
RoHS:
Yes
HTS:
8536490075
COO:
PT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
Tube
Relay Mounting Type:
Printed Circuit Board
Coil Power Rating Class:
800 – 1000 mW
Contact Material:
AgSnO
Power Relay Type:
Standard
Contact Switching Load (Min):
1A @ 12V
Insulation Initial Dielectric Between Open Contacts:
4000 Vrms
Contact Number of Poles:
1
Contact Switching Voltage (Max):
480 VAC
Terminal Type:
PCB-THT
Coil Power Rating (DC):
900 mW
Product Length:
29 mm
Dimensions (L x W x H) (Approximate):
1.142 x .846 x .618 in, 29 x 21.5 x 15.7 mm
Contact Current Class:
20 – 30 A
Environmental Ambient Temperature (Max):
105 °C, 85 °C, 176 °F, 221 °F
Coil Voltage Rating:
12 VDC
Operating Temperature Range:
-40 – 105 °C
Contact Current Rating (Max):
30 A
Relay Termination Type:
Printed Circuit Terminals
Height Class (Mechanical):
15 – 16 mm
Product Weight:
18 g, .635 oz
Width Class (Mechanical):
20 – 25 mm
Coil Magnetic System:
Monostable, DC
Coil Special Features:
UL Coil Insulation Class F
Product Width:
.846 in, 21.5 mm
Environmental Category of Protection:
RTII
Length Class (Mechanical):
25 – 30 mm
Contact Arrangement:
1 Form A (NO)
Packaging Method:
Carton & Tube
Insulation Initial Dielectric Between Contacts & Coil:
2500 Vrms
Contact Voltage Rating:
250 VAC
Coil Resistance:
160 Ω
Product Height:
.618 in, 15.7 mm
The T9GV1L14-12 is a high-quality electromechanical relay from TE Connectivity's P&B brand. This relay is reliable and designed for use in various applications that require a powerful switching capability. With its compact size and robust construction, the T9GV1L14-12 is ideal for use in industrial machinery, automation systems, and power distribution equipment. This relay features 1 form A contact configuration, a coil voltage of 12V, and a switching current of up to 30A. Trust the T9GV1L14-12 to deliver excellent performance and long-lasting durability in your electrical projects.
Search Keywords:
T9GV1L1412
IN STOCK: 0
Minimum Order Quantity:
30
Multiple:
10
Factory Lead-Time
24 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
30
$3.79
$113.70
50
$2.77
$138.50
100
$2.72
$272.00
250
$2.66
$665.00
500
$2.64
$1,320.00
1,000
$2.62
$2,620.00
2,500
$2.61
$6,525.00
5,000 +
$2.60
$13,000.00
Please Note: Tariffs may apply for U.S. shipments
