V23079D1005B301 by te connectivity / p-b brand
Image is representational - see mfr. specs
DATA SHEET

V23079D1005B301

TE Connectivity / P&B Brand

Signal Relay - 2 form C - Bistable, 1 coils - Contacts: AgNi +Au, 2A 250VAC - Coil: 24VDC, 8228 ohm - PCB Thru Hole .. see full description

RoHS Compliant
Reel Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23079D1005B301
Alias/AKA:
5-1393788-8
RoHS:
Yes
HTS:
8536490080
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14.5 x 10.4 x 9.4 mm
Termination Style:
Gull Wing
Coil Current:
5.83 mA
Contact Form:
2 Form C
TE Connectivity / P&B Brand part V23079D1005B301 is a high-quality signal relay designed for use in various applications such as automotive and medical industries. This relay operates on a 24VDC voltage with a maximum current rating of 2A. It features a DPDT (Double Pole Double Throw) configuration, providing reliable switching between two separate circuits. With its compact dimensions of 14.5x9.4x10.4mm and surface-mount design, this relay offers easy installation and efficient space utilization. Whether used in vehicle control systems or medical devices, this TE Connectivity / P&B relay delivers exceptional performance and durability.
Product Highlights:
  • V23079 / P2 Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.
Search Keywords:
V23079D1005B301
IN STOCK: 1,811
Can Ship immediately
On Order:
50,000   can ship 4/7/27
48,811   can ship 4/28/27
Minimum Order Quantity:
100
Factory Lead-Time
50 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$2.56
$256.00
400
$2.48
$992.00
800
$2.24
$1,792.00
1,200
$2.22
$2,664.00
2,800
$2.20
$6,160.00
5,200
$2.18
$11,336.00
7,600
$2.16
$16,416.00
10,000 +
$2.14
$21,400.00
