V23105A5307A201 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
DATA SHEET

V23105A5307A201

TE Connectivity / P&B Brand

Signal Relay - 2 form C - Contacts: AgNi+Au, 3A - Coil: 48VDC, 200mW - Thru Hole .. see full description

RoHS Compliant
Packaging
Accessories
Discontinued
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23105A5307A201
Alias/AKA:
1393793-3
RoHS:
Yes
HTS:
8536490075
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
48 V
Contact Arrangement:
DPDT
Maximum Current Rating:
3 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Termination Style:
PC Pin
Coil Current:
4.17 mA
Contact Form:
2 Form C
Life Cycle:
Discontinued
The TE Connectivity / P&B Brand part V23105A5307A201 is a compact and reliable signal relay designed for various electronic applications. This relay is compatible with a 48VDC power supply and can handle up to 3A current. Its DPDT configuration allows for versatile switching options. With its compact dimensions of 20.2mm x 10mm x 11mm, this through-hole mountable relay can easily fit into compact electronic devices. It provides robust performance and long-lasting durability, making it an ideal choice for applications requiring high-quality signal switching.
Product Highlights:
  • V23105 / D2n Relay Series
  • DC Actuating System
  • Input Voltage = 48 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 3 Amps.
Search Keywords:
V23105A5307A201
  This product is discontinued, but still in stock
IN STOCK: 10,557
Can Ship immediately
Minimum Order Quantity:
25
Price (USD)
Quantity
Unit Price
Ext. Price
25
$3.17
$79.25
150
$3.11
$466.50
250
$3.06
$765.00
450
$3.00
$1,350.00
2,000
$2.94
$5,880.00
5,000
$2.55
$12,750.00
10,000 +
$2.20
$22,000.00
