F20-300 by triad magnetics
Image is representational - see manufacturer specifications
DATA SHEET

F20-300

Triad Magnetics

Power Transformer 2500Vrms 6VA 6Term. PC Pin Thru-Hole .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Triad Magnetics
Part No:
F20-300
RoHS:
Yes
HTS:
8504314035
COO:
PH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Primary Configuration:
Single
Primary Side Voltage:
115 V
Secondary Configuration:
Dual
Secondary Side Voltage:
20,10 V
Secondary Side Current:
300,600 mA
Power Rating:
6 VA
Mounting:
Through Hole
Dimension:
41.3 x 33.34 x 33.34 mm
The TRIAD MAGNETICS part F20-300 is a power transformer designed for various electronic applications. It features an impressive 2500Vrms voltage rating, making it suitable for use in high voltage circuits. With a power rating of 6VA, this transformer can efficiently handle power requirements up to 6 watts. It is equipped with 6 terminals for easy connection and comes with PC pin thru-hole mounting for convenient installation on PCB boards. This compact and reliable transformer offers exceptional performance and is ideal for a wide range of electronic projects.
Search Keywords:
F20300
IN STOCK: 0
Minimum Order Quantity:
5
Factory Lead-Time
19 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$16.02
$80.10
25
$10.41
$260.25
50
$9.44
$472.00
100
$9.02
$902.00
250
$8.37
$2,092.50
500
$8.00
$4,000.00
1,000
$7.74
$7,740.00
2,500 +
$7.68
$19,200.00
Product Guides
PDF Datasheet
