3361P-1-504GLF by bourns
图片仅供参考 - 请查看制造商规格
产品说明书

3361P-1-504GLF

Bourns

Trimmer Potentiometer - 500K Ohm - 0.5W(1/2W) - 1(Elec)/1(Mech)Turn - 6.71 X 8.53 X 5.21mm - Gull Wing - Surface Mount. .. 查看完整描述

符合 RoHS
REEL 包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. 合规证书保证
产品属性
属性值 选择属性
找到的产品: 0
供应商:
Bourns
部件编号:
3361P-1-504GLF
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
供应商标准包装 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
750
封装类型:
REEL
安装方式:
Surface Mount
匝数:
1(Elec),1(Mech) Tur ns
端接方式:
Gull Wing
额定功率:
0.5 (1/2) W
电阻值:
500 KOhm
公差:
10 %
温度系数:
±100 ppm/°C
尺寸:
6.71 x 8.53 x 5.21 mm
工作温度:
-55 to 125 °C
开关选项:
No
元件数量:
1
The 3361P-1-504GLF is a 500kR 500mW 1/4-inch square SMD Trimming Potentiometer with 100% tin-plated solderable pin terminals. The Trimpot® potentiometer features infinite resolution, 240° nominal adjustment angle, withstands harsh environments and immersion cleaning processes. Adjustability of ±0.05% voltage ratio and ±0.15% resistance ratio. Stable cermet element offers infinite resolution. Operating temperature ranges from -55°C to +125°C.
搜索关键词:
3361P1504GLF
有存货: 300
发货 today, 输入设置值。
购买全部 300 个现货或常规最小订购数量 750
已订购:
6,000   可以发货 9/7/26
仅库存批次:
300
最小订购数量:
750
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。:
750
工厂交货期
12 周
价格 (USD)
数量
单价
总价
1
$0.6015
$0.6015
750
$0.5468
$410.1000
1,500
$0.5215
$782.2500
3,000
$0.5122
$1,536.6000
5,250
$0.5063
$2,658.0750
7,500
$0.4917
$3,687.7500
10,500
$0.4893
$5,137.6500
15,000
$0.4868
$7,302.0000
25,500 +
$0.4856
$12,382.8000
