4TL1-3D
HoneywellMICRO SWITCH™ Toggle Switches: TL Series, 4 Pole Double Throw (4PDT) 2 Position (On - On), Screw Terminals, Locking Lever (Locked Out Of Center Position), Military Part Number MS24660-23D .. 查看完整描述
产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
4TL1-3D
别名/又称:
MS24660-23D
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
供应商标准包装
1
封装类型:
Bulk
极-位配置:
4P2T (4PDT)
开关配置:
On None On
触点额定电流 @ 电压:
20@28VDC A
致动器样式:
Locking Lever
安装方式:
Panel Mount with Threads
螺纹尺寸:
15/32-32
本体方向:
Straight
端子类型:
Screw
尺寸:
33.5 x 41.6 x 72.9 mm
工作温度:
-65 to 71 °C
<p>The 4TL1-3D Toggle Switch from Honeywell is ideal for various military, aerospace and other harsh environment applications. This Honeywell Toggle Switch features environment-proof sealing, temperature resistance and silver cadmium oxide contacts. It is also designed with a pull-to-unlock toggle lever to avert accidental operation. Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism.</p>
<p>This In-Line Toggle Switch enables both maintained and momentary toggle action. These electrical switches are available in different styles and sizes. They are generally used in industrial machinery and equipment, military and commercial aviation, construction equipment, test instruments, agricultural machinery, process control, and medical instrumentation, among others.</p>
产品亮点:
- UL recognized, CSA certified
- CE approved
- Qualified to MIL-DTL-3950
- 1, 2, and 4 pole circuitry
- Environment-proof sealing
- Standard and pull-to-unlock levers
- 2 and 3 position, maintained and momentary toggle action
- Completely sealed switching chamber
- Temperature range: -85°F to +160°F
- Step-design case provides added space between terminals to help prevent shorting
潜在应用:
<ul><li>Industrial machinery and equipment</li><li>Military and commercial aviation</li><li>Construction equipment</li><li>Test instruments</li><li>Agricultural machinery</li><li>Process control</li><li>Medical instrumentation</li></ul>搜索关键词:
4TL13D
有存货:
357
发货 today, 输入设置值。
工厂交货期
7 周
价格 (USD)
数量
单价
总价
1
$106.46
$106.46
5
$100.20
$501.00
10
$96.24
$962.40
20
$93.81
$1,876.20
50
$90.80
$4,540.00
100
+
$89.23
$8,923.00
