BAF1-2RN18-LH by honeywell
Image is representational - see mfr. specs
产品说明书

BAF1-2RN18-LH

Honeywell

Snap Action Switch - SPDT - On-Mom - 20A(AC)/500mA(DC) 125VAC/DC - Spring, Coil Actuator Mounted On Left Side - Screw Terminal - Chassis Mount. .. see full description

符合 RoHS 规定
包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
供应商:
Honeywell
部件编号:
BAF1-2RN18-LH
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
供应商标准包装 This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Enclosed
Actuator Style:
Coil Spring
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
101.6 x 33 x 185.9 mm
Maximum Current Rating:
0.5@125VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 13
Body Orientation:
Straight
The BAF1-2RN18-LH is snap action switch with operating temperature range from -32°C to 71°C.
Product Highlights:
  • Sealed to NEMA 1, 3, 4 and 13 requirements
  • Grounding screw
  • Up to 20 ampere capacity
  • Cast aluminum housing with three-hole mounting
  • Right or left-handed (sealed or unsealed) actuators
  • Cover seal, captive cover screws
  • Momentary or maintained contact
  • UL recognized, file #E12252
  • CSA certified, file #LR41372
Potential Applications:
<ul><li>Packaging equipment </li><li>Special machinery</li><li>Agricultural machinery </li><li>Conveyors</li><li>Overhead cranes and hoists</li></ul>
Search Keywords:
BAF12RN18LH
有存货: 48
Ships today, if you order in
工厂交货期
5 周
PRICE (USD)
Quantity
Unit Price
Ext. Price
1
$310.78
$310.78
3
$307.75
$923.25
5 +
$306.98
$1,534.90
