AP8M222-G by idec corporation
图片仅供参考 - 请查看制造商规格
产品说明书

AP8M222-G

IDEC Corporation

LED Panel Mount Indicator Uni-Color Green 2-Pin .. 查看完整描述

符合 RoHS
包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. 合规证书保证
产品属性
属性值 选择属性
找到的产品: 0
供应商:
IDEC Corporation
部件编号:
AP8M222-G
RoHS:
Yes
HTS:
8541402000
COO:
JP
ECCN:
EAR99
供应商标准包装 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
安装方式:
Panel
尺寸:
31 x 9.8 mm
类型:
Uni-Color
每种颜色最大正向电压:
26.4 V
颜色:
Green
峰值波长:
N/A
透镜形状类型:
Circular
镜片外观:
N/A
镜片尺寸:
N/A
强度:
N/A
视角:
N/A
最大正向电流:
9 mA
The AP8M222-G is a miniature 8mm pilot light from IDEC's AP Series, featuring a built-in LED with integrated current-limiting resistor and a dome lens design. It operates at 24V AC/DC (±10% tolerance) with a current rating of 15mA for AC and 9mA for DC, providing reliable visual indication in compact panel-mounted applications. The unit is rated for operating temperatures from -20°C to +55°C with 45–85% RH humidity, and offers IP40 protection (dustproof). With an insulation resistance of 100MO minimum and a reverse withstand voltage of 200V, this pilot light is suitable for industrial control panels, machinery status indication, and process monitoring systems where space is limited and long service life is required.
搜索关键词:
AP8M222G
有存货: 44
可立即发货
最小订购数量:
5
工厂交货期
9 周
价格 (USD)
数量
单价
总价
5
$16.60
$83.00
25
$12.83
$320.75
50
$12.12
$606.00
100
$9.89
$989.00
250
$9.58
$2,395.00
500
$9.17
$4,585.00
1,000 +
$9.15
$9,150.00
