NL8FC by neutrik
Image is representational - see mfr. specs
产品说明书

NL8FC

NEUTRIK

FC Series - 8 pole cable connector, latch lock - chuck type strain relief for cables 8 - 20 mm diameter - 30 A continuous per contact The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable .. see full description

符合 RoHS 规定
包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
供应商:
NEUTRIK
部件编号:
NL8FC
RoHS:
Yes
HTS:
8536694020.00
COO:
LI
ECCN:
EAR99
供应商标准包装 This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Type:
Speakon
Gender:
F
Body Orientation:
Straight
Mounting:
Cable Mount
Housing Material:
Polybutylene Terephthalate
Number of Contacts:
8
Contact Plating:
Silver
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
The NL8FC is 8 pole cable connector, latch lock, chuck type strain relief for cables 8 - 20 mm diameter, 30 A continuous per contact The NL8FC has rated current per contact of 30 A rms continuous. The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which offer also solder termination.
Product Highlights:
  • Current rating 30 A rms continuous
  • Reliable and robust, easy and fast to assemble
  • Contacts are touch proof and meet all safety requirements (IEC, UL, CSA)
  • Accurate and dependable twist lock latching system "Quick Lock"
  • High impact material for insert and housing, long-lasting and dependable
  • Chuck type strain relief system for secure clamping of cable
Search Keywords:
NL8FC
有存货: 407
Ships today, if you order in
Minimum Order Quantity:
5
工厂交货期
3 周
PRICE (USD)
Quantity
Unit Price
Ext. Price
5
$17.58
$87.90
25
$15.26
$381.50
50
$15.15
$757.50
100
$15.07
$1,507.00
250
$15.04
$3,760.00
500
$15.00
$7,500.00
1,000 +
$14.96
$14,960.00
