1-770966-0 by te connectivity / amp brand
图片仅供参考 - 请查看制造商规格
产品说明书

1-770966-0

TE Connectivity / AMP Brand

Wire-To-Board Connector - Right Angle - 4.14 mm - 2 Contacts - Header - Mini Universal MATE-N-LOK Series. .. 查看完整描述

符合 RoHS
BAG 包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. 合规证书保证
产品属性
属性值 选择属性
找到的产品: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
1-770966-0
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
供应商标准包装 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
200
封装类型:
BAG
类型:
Power
本体方向:
Right Angle
安装方式:
Through Hole
公母类型:
HDR
触点数量:
2
端接方式:
Solder
最大电压额定值:
600 VAC
最大电流额定值:
9.5/Contact A
工作温度:
N/A
The 1-770966-0 is Mini Universal MATE-N-LOK right angle mount PCB pin headers with 4.14mm centerline for wire to board applications preloaded with tin or gold plated pin contacts. These Mini Universal MATE-N-LOK right angle mount PCB pin headers have white UL94V-0 nylon housings that incorporate a positive locking latch mechansim to ensure secure mating and board locks to facilitate PCB retention.
产品亮点:
  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 2
  • 4.14 mm Centerline, Matrix
  • In-Line Contact Layout
搜索关键词:
17709660
有存货: 13,801
发货 today, 输入设置值。
已订购:
11,200   可以发货 10/14/26
最小订购数量:
200
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。:
200
工厂交货期
17 周
价格 (USD)
数量
单价
总价
200
$0.786
$157.200
400
$0.768
$307.200
600
$0.767
$460.200
1,000
$0.744
$744.000
2,600
$0.727
$1,890.200
5,000
$0.725
$3,625.000
7,600
$0.723
$5,494.800
10,000 +
$0.721
$7,210.000
