DT06-3S-E005 by te connectivity / deutsch automotive
图片仅供参考 - 请查看制造商规格
产品说明书

DT06-3S-E005

TE Connectivity / Deutsch Automotive

PLG, 3P, BLK, N, CAP .. 查看完整描述

符合 RoHS
Pack 包装
附件
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. 合规证书保证
产品属性
属性值 选择属性
找到的产品: 0
供应商:
TE Connectivity / Deutsch Automotive
部件编号:
DT06-3S-E005
RoHS:
Yes
HTS:
8538908180
COO:
US
ECCN:
EAR99
供应商标准包装 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
封装类型:
Pack
长度:
1.178 in, 29.92 mm
宽度:
.737 in, 18.71 mm
主锁定结构:
Integrated in Housing
额定电压架构:
12 V, 24 V, 48 V
电缆出口角度:
180 °
工作温度（最大）:
125 °C, 257 °F
支持连接器位置保护装置:
No
UL 阻燃等级:
12mm Flame Test per Standard UL-94
连接器系统:
Wire-to-Wire
极化型:
Yes
本体材料:
PA GF
包装数量:
1200
包装方式:
Box
配合插针直径:
.0625 in, 1.59 mm
位置数量:
3
工作温度范围:
-55 – 125 °C, -67 – 257 °F
工作电压:
250 VAC
可密封:
Yes
防护等级:
IP68 , IP6K9K
连接器与外壳类型:
Housing for female terminals
可维修:
Yes
端子位置保证:
Yes
应力消除装置:
Add By Accessory
混合连接器:
No
主要产品颜色:
Black
认证机构/标准:
SAE J2030
安装特征:
Without
电路应用:
Power & Signal
空腔位置:
0
高度:
.94 in, 23.89 mm
触点额定电流（最大）:
13 A
中心距（间距）:
.394 in, 10.01 mm
The TE CONNECTIVITY / DEUTSCH AUTOMOTIVE part DT06-3S-E005 is a high-quality connector plug designed for reliable performance in demanding automotive and industrial applications. This 3-position plug, finished in a sleek black color, is engineered to provide secure and robust connectivity. It features a durable and rugged construction that ensures enhanced resistance to environmental factors and mechanical stress. With a built-in cap, this connector offers additional protection against dust, moisture, and other contaminants, making it suitable for use in harsh conditions. The DT06-3S-E005 is a trusted solution for ensuring long-lasting connections in critical systems, providing peace of mind and superior reliability for engineers and technicians. This connector is ideal for use in wiring harnesses, power distribution, and signal transmission in vehicles and heavy machinery.
搜索关键词:
DT063SE005
有存货: 210
可立即发货
已订购:
1,200   可以发货 10/22/26
最小订购数量:
25
工厂交货期
14 周
价格 (USD)
数量
单价
总价
25
$1.593
$39.825
250
$0.945
$236.250
500
$0.936
$468.000
1,000
$0.922
$922.000
2,500
$0.912
$2,280.000
5,000
$0.907
$4,535.000
7,500
$0.905
$6,787.500
10,000 +
$0.903
$9,030.000
