56.706.0053.0

Wieland Electric

Conn Feed-Through Terminal Block F 2 POS ST T DIN Rail 40A .. 查看完整描述

符合 RoHS
包装
附件
税 05/01/2026
附件
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. 合规证书保证
产品属性
属性值 选择属性
找到的产品: 0
供应商:
Wieland Electric
部件编号:
56.706.0053.0
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
供应商标准包装 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
100
本体方向:
Straight
End of Life:
创建时间 05/01/2026
The 56.706.0053.0 is a WKF 6/35 feed-through terminal block designed for DIN rail mounting with spring clamp connection technology. It accommodates fine stranded and solid conductors ranging from 0.5 to 6 mm² (AWG 20–8), with a rated current capacity of 41 A and voltage rating of 800 V (8 kV impulse, 3 kV AC). The block features a width of 8 mm and wire strip length of 12 mm, complying with EN 60 947-7-1 and DIN VDE 0611 T1 standards. It is commonly used in industrial electrical installations, control panels, and power distribution systems where reliable, space-efficient connections are required.
搜索关键词:
5670600530
  税 05/01/2026
有存货: 174
发货 today, 输入设置值。
最小订购数量:
100
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时,订单会获得已付款状态。:
100
工厂交货期
3 周
价格 (USD)
数量
单价
总价
100
$1.76
$176.00
300
$1.72
$516.00
500
$1.70
$850.00
1,000
$1.65
$1,650.00
2,500
$1.63
$4,075.00
5,000
$1.61
$8,050.00
7,500
$1.60
$12,000.00
10,000 +
$1.59
$15,900.00
