1658613-3
TE Connectivity / AMP BrandD Sub Connector - DB15 - 15 Contacts - Plug - IDC / IDT - DA - Amplimite HDF-20 Series - Metal Body. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658613-3
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack
40
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
2
Number of Contacts:
15
Contact Plating:
Gold Over Palladium Nickel,Gold Over Nickel
Operating Temperature:
-55 to 105 °C
The 1658613-3 is a 15-position 2-row standard IDC D-sub Plug with gold-plated phosphor bronze contacts, black thermoplastic housing and standard mounting holes mating connector lock. The Amplimite HDF-20 series D-sub connector has tin-plated bright steel shell, grounding indents and thermoplastic protective cover. The D-sub connector is suitable for flat ribbon cable.
Product Highlights:
- Connector
- Product Series = HDF-20 (Ribbon Cable)
- Number of Positions = 15
- Plug
- With Contacts
Search Keywords:
16586133
IN STOCK:
238
Ships today, if you order in
Minimum Order Quantity:
5
Factory Lead-Time
2 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$7.333
$36.665
40
$3.503
$140.120
80
$2.796
$223.680
120
$2.709
$325.080
280
$2.624
$734.720
520
$2.611
$1,357.720
1,000
$2.598
$2,598.000
2,520
+
$2.585
$6,514.200
Please Note:
Tariffs may apply for U.S. shipments
Product Guides
Product Drawing - PLUG ASSEMBLY, FRONT METAL SHELL, LEAD-FREE, AMPLIMITE HDF
Datasheet
Product Specification - AMPLIMITE HDF-20 Low Profile Connector
