KUP-11D11-24 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
DATA SHEET

KUP-11D11-24

TE Connectivity / P&B Brand

Power Relay 24VDC 5A DPDT(39.4x35.7x50)mm Socket .. see full description

RoHS Compliant
BAG Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUP-11D11-24
Alias/AKA:
4-1393117-2
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Package Type:
BAG
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
5 A
Mounting:
Socket
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
472 Ohm
The TE Connectivity / P&B Brand part KUP-11D11-24 is a reliable and high-quality power relay designed for various applications. With a voltage rating of 24VDC and a current rating of 5A, this relay ensures efficient and safe operation. It features a DPDT (Double Pole Double Throw) configuration, providing versatility in switching between two independent circuits. The compact dimensions of 39.4x35.7x50mm make it suitable for space-constrained environments. The included socket facilitates easy installation and enhances the overall reliability of the relay. Trust TE Connectivity / P&B Brand for dependable and durable power relays to meet your electrical needs.
Product Highlights:
  • KUP Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 5 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
KUP11D1124
  Possible Replacement options available.  See Alternatives
IN STOCK: 233
Can Ship immediately
Factory Lead-Time
25 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$31.17
$31.17
5
$28.82
$144.10
10
$26.31
$263.10
25
$24.60
$615.00
50
$23.37
$1,168.50
100
$21.03
$2,103.00
250 +
$20.98
$5,245.00
