The 9188A-WH005 is a high-temperature, military-grade coaxial cable designed for reliable signal transmission. It is constructed with a 25 AWG silver-coated copper weld conductor, PTFE insulation, and a silver-plated copper braid shield that provides a minimum of 94% coverage. The cable, which has a white PTFE tape jacket and a nominal outer diameter of 0.105 inches, features a characteristic impedance of 50 Ohms. It is rated for an operating temperature range of -55°C to 200°C and a voltage of 900 VRMS. As a MIL-C-17D/69B RG 188A/U type cable, it is ideal for demanding military, aerospace, and high-performance electronic applications.
