The 69830-020LF is a QUICKIE DIL PCB connector designed for 20-position dual-in-line applications with short legs. It features a polyester (PET) glass-filled base material (UL94V-0, blue color) with phosphor bronze terminals finished in pure tin plating (3.81 µm minimum) over nickel underplating (1.27 µm minimum), meeting lead-free (LF) requirements. The connector has a contact retention force of 400 gf/pin minimum and is rated to withstand 260°C peak temperature for 5 seconds in wave solder applications. With a pitch of 2.54 mm and mounting hole diameter of 0.80 mm, this connector is ideal for PCB-mounted applications requiring reliable, compact interconnections in industrial and consumer electronics.
