AFB0412SHB
Delta Thermal / EMI / SolenoidsDC Fans DC Axial Fan - 40x15mm - 12VDC .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Delta Thermal / EMI / Solenoids
Nº de pieza:
AFB0412SHB
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Paquete estándar del proveedor
448
Category:
DC Fan
Dimension:
40 x 40 x 15 mm
Voltage Rating:
12 V
Power Rating:
3 W
Maximum Airflow:
14.8 CFM
Noise Level:
41.5 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A
The AFB0412SHB is a DC Fan Axial Voltage - Rated 12VDC
Size / Dimension Square - 40mm L x 40mm H
Width 15.00mm
Air Flow 14.8 CFM (0.414m³/min)
Static Pressure 0.601 in H2O (149.7 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Noise 41.5 dB(A)
Power (Watts) 3.00W
RPM 11000 RPM
Termination 2 Wire Leads
Operating Temperature 14 ~ 158°F (-10 ~ 70°C)
Approvals CE, CSA, UL, VDE
Weight 0.055 lb (24.95g)
Current Rating (Amps) 0.250A
Voltage Range 7 ~ 13.8VDC
Material - Frame Plastic
Material - Blade Plastic
Lifetime @ Temp. 70000 Hrs @ 40°C
Palabras clave de búsqueda:
AFB0412SHB
EN STOCK:
179
Puede enviar inmediatamente
A la orden:
448
puede enviar 5/27/26
MOQ para Cantidad en Stock:
5
MOQ para cantidad agotada:
224
Plazo de entrega de fábrica
51 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$12.39
$61.95
50
$9.85
$492.50
100
$9.16
$916.00
224
$9.11
$2,040.64
448
$8.72
$3,906.56
672
$8.70
$5,846.40
896
+
$8.68
$7,777.28
FICHA TÉCNICA
