AFB0412SHB-SP04 by delta thermal / emi / solenoids
Imagen de referencia - consulte las especificaciones del fabricante
FICHA TÉCNICA

AFB0412SHB-SP04

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 40x15mm - 12VDC - 14.83CFM - 1.92W - 0.16A - 41.5dBA - 11000RPM - Ball Bearing - PWM .. Ver descripción completa

Cumple con RoHS
Bulk embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad
Atributo del producto
Valor del atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Delta Thermal / EMI / Solenoids
Nº de pieza:
AFB0412SHB-SP04
RoHS:
Yes
HTS:
8414596590
COO:
CN
ECCN:
EAR99
Empaque estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precio y disponibilidad.
448
Tipo de encapsulado:
Bulk
Categoría:
DC Fan
Dimensión:
40 x 40 x 15 mm
Tensión Nominal:
12 V
Potencia nominal:
1.92 W
Flujo de Aire Máximo:
14.8 CFM
Nivel de ruido:
41.5 dB
Señal del Tacómetro:
Yes
Señal de Control PWM:
Yes
Características Especiales:
Tachometer Output, PWM speed control
Terminación:
Lead Wires
Material de la Carcasa:
Plastic
Temperatura de Funcionamiento:
-10 to 70 °C
Delta Electronics Ingress Protection Fans feature built-in resistance to environmental conditions such as dust, water and foreign objects that can disable and damage fans and thermal cooling equipment. Delta Electronics Ingress Protection (IP) fans provide IP55 and higher protection as an industry standard, offering protection against the intrusion of solid objects such as hands and fingers, as well as dust or dirt exposure, accidental contact, and water in the form of salt fog, moisture, or precipitation. Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 15.00mm Air Flow 14.8 CFM (0.414m³/min) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 41.5 dB(A) Power (Watts) 1.92W RPM 11000 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Weight 0.055 lb (24.95g) Current Rating (Amps) 0.160A Voltage Range 10.8 ~ 13.2VDC
Palabras clave de búsqueda:
AFB0412SHBSP04
EN STOCK: 0
A la orden:
2.249   puede enviar 11/23/26
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
39 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
5
$12.14
$60.70
25
$10.30
$257.50
50
$10.22
$511.00
100
$10.17
$1,017.00
448
$10.15
$4,547.20
896
$10.12
$9,067.52
1.344 +
$10.10
$13,574.40
