AFB0524HHB
Delta Thermal / EMI / SolenoidsDC Fans DC Axial Fan - 50x15mm - 24VDC .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Delta Thermal / EMI / Solenoids
Nº de pieza:
AFB0524HHB
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Paquete estándar del proveedor
336
Tipo de paquete:
Bulk
Category:
DC Fan
Dimension:
50 x 50 x 15 mm
Voltage Rating:
24 V
Power Rating:
1.92 W
Maximum Airflow:
16.2CFM
Noise Level:
36 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A
The AFB0524HHB is a DC Axial Fan Voltage - Rated 24VDC
Size / Dimension Square - 50mm L x 50mm H
Width 15.00mm
Air Flow 16.2 CFM (0.454m³/min)
Static Pressure 0.315 in H2O (78.5 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Noise 36.0 dB(A)
Power (Watts) 1.92W
RPM 6400 RPM
Termination 2 Wire Leads
Operating Temperature 14 ~ 158°F (-10 ~ 70°C)
Approvals CE, CSA, UL, VDE
Weight 0.071 lb (32.21g)
Current Rating (Amps) 0.080A
Voltage Range 14 ~ 27.6VDC
Material - Frame Plastic
Material - Blade Plastic
Lifetime @ Temp. 70000 Hrs @ 40°C
