AFB1224VHE-R00
Delta Thermal / EMI / SolenoidsAxial Square-120mm L x 120mm H x 38 mm W 24VDC 3 Wire Leads Locked Rotor Sensor .. Ver descripción completa
Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Delta Thermal / EMI / Solenoids
Nº de pieza:
AFB1224VHE-R00
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Empaque estándar del proveedor
36
Tipo de encapsulado:
Box
Categoría:
DC Fan
Dimensión:
120 x 120 x 38 mm
Tensión Nominal:
24 V
Potencia nominal:
9.12 W
Flujo de Aire Máximo:
129 CFM
Nivel de ruido:
48 dB
Señal de detección de rotación:
Yes
Características Especiales:
Speed/Rotation/Rotor-Lock Alarm
Terminación:
Lead Wires
Material de la Carcasa:
Plastic
Temperatura de Funcionamiento:
N/A
The DELTA AFB1224VHE-R00 is a DC fan designed to provide efficient and reliable cooling for various electronic components and systems. With its ball bearing technology, this fan offers enhanced durability and long-lasting performance. Operating at 24V, consuming 0.38A and 9.12W of power, it delivers powerful airflow with a maximum speed of 3200 RPM, ensuring effective heat dissipation. With a flow rate of 129.96 cubic feet per minute (CFM), this fan offers excellent ventilation, keeping critical components at optimal temperatures. Additionally, the fan operates quietly at 48dB, allowing for minimal noise disruption. Its flange mount design provides easy installation and secure placement. Ideal for a wide range of applications, this Delta fan is a dependable choice for cooling requirements in diverse electronic systems.
Palabras clave de búsqueda:
AFB1224VHER00
EN STOCK:
109
Puede enviar inmediatamente
A la orden:
526
puede enviar 2/17/27
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
34 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
5
$22.92
$114.60
10
$18.09
$180.90
36
$15.25
$549.00
72
$15.18
$1,092.96
108
$14.60
$1,576.80
252
$14.56
$3,669.12
504
+
$14.52
$7,318.08
