CH60J3I by eaton electrical / coiltronics / bussmann
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

CH60J3I

Eaton Electrical / Coiltronics / Bussmann

Fuse Holder 60A GANGING ASSEMBLY 3 P INDICATING .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Eaton Electrical / Coiltronics / Bussmann
Nº de pieza:
CH60J3I
RoHS:
Yes
HTS:
8536908585
COO:
CN
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
2
CH60J3I is a 3-pole modular fuse holder designed for Class J fuses rated from 35A to 60A at 600Vac/dc. It features a neon lamp open fuse indicator with a minimum indicating voltage of 90Vac/115Vdc and nominal operating current of 34mA at 460Vac. The holder accommodates wire ranges from 18-1AWG single or 18-3AWG dual at 75°C, with terminal torque specifications of 24in-lb for 10-18AWG and 35in-lb for 1-8AWG wires. Constructed with tin-plated copper clips and UL 94V0 thermoplastic housing, it meets IP20 finger-safe requirements per IEC 60529 and supports 36mm DIN rail or panel mounting. This fuse holder is ideal for industrial power distribution applications requiring reliable overcurrent protection with visual indication.
Palabras clave de búsqueda:
CH60J3I
EN STOCK: 0
A la orden:
2   puede enviar 7/16/26
Cantidad mínima de pedido:
2
Plazo de entrega de fábrica
21 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
2
$510.12
$1,020.24
4
$488.87
$1,955.48
6 +
$420.12
$2,520.72
