14SX15-T by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

14SX15-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 1 A 125 Vac, Gold Alloy Contacts, 1,39 N [5.0 oz] Maximum Operating Force, Pin Plunger Actuator, Single Turret Solder Termination, High Temperature Construction 163 °C [325 °F], 4,83 mm [0.19 in] Mounting Centers, UL, CE, CSA, ENEC .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
14SX15-T
RoHS:
Yes
HTS:
85365007
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
200
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Plunger
Contact Rating @ Voltage:
1 A
Maximum Movement Differential:
0.05 mm
Operating Force:
1.39 N
Termination Style:
Solder
Dimension:
12.7 x 5.08 x 12.7 mm
Body Orientation:
Straight
IP Rating:
N/A
The HONEYWELL part 14SX15-T is a high-quality MICRO SWITCH„¢ subminiature basic switch from the SX series. With a single pole double throw (SPDT) configuration, it is capable of handling 1 A at 125 Vac and features gold alloy contacts for reliable electrical connections. Operating at a maximum force of 1.39 N (5.0 oz), this switch has a pin plunger actuator for precise and accurate operation. It is equipped with a single turret solder termination for easy installation. Designed for high-temperature applications, this switch can withstand temperatures up to 163 °C (325 °F), making it suitable for a wide range of industries and environments. It has mounting centers of 4.83 mm (0.19 in), providing flexibility in installation. Additionally, the HONEYWELL part 14SX15-T meets the standards of UL, CE, CSA, and ENEC, ensuring its compliance with safety and performance regulations. With its superior features and reliable performance, this switch is an excellent choice for various industrial and commercial applications.
Características destacadas del producto:
  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of operating characteristics
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 7 A)
  • MIL-PRF-8805 qualified listings available
Aplicaciones potenciales:
<ul><li>Aerospace</li><li>Appliances</li><li>Vending machines</li><li>Timing devices</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Palabras clave de búsqueda:
14SX15T
EN STOCK: 0
A la orden:
150   puede enviar 8/10/26
MOQ para cantidad agotada:
50
Plazo de entrega de fábrica
19 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$122.20
$122.20
10
$121.89
$1,218.90
25
$121.59
$3,039.75
50
$121.28
$6,064.00
100
$64.01
$6,401.00
150
$44.02
$6,603.00
200 +
$43.14
$8,628.00
Suppliers Standard Package
