2TL1-6 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

2TL1-6

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Single Throw (DPST) 2 Position (Mom. On - Off), Screw Terminals, Standard Lever, Military Part Number MS24524-30 .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
2TL1-6
Alias/alias:
MS24524-30
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None (ON)
Contact Rating @ Voltage:
372.85 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 63.47mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL part 2TL1-6 is a MICRO SWITCHâ„¢ toggle switch from the TL Series. It is a double pole single throw (DPST) switch with 2 positions - momentary on and off. The switch is equipped with screw terminals for easy and secure connection. It features a standard lever and is a military-grade switch with part number MS24524-30. This toggle switch is highly reliable and perfect for a wide range of applications.
Características destacadas del producto:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Aplicaciones potenciales:
<ul><li>Industrial machinery and equipment</li><li>Military and commercial aviation</li><li>Construction equipment</li><li>Test instruments</li><li>Agricultural machinery</li><li>Process control</li><li>Medical instrumentation</li></ul>
Palabras clave de búsqueda:
2TL16
EN STOCK: 136
Puede enviar inmediatamente
Plazo de entrega de fábrica
19 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$55.56
$55.56
5
$40.61
$203.05
10
$39.79
$397.90
25
$37.34
$933.50
50
$36.77
$1,838.50
100
$36.68
$3,668.00
250 +
$36.59
$9,147.50
Haga clic para obtener una cotización
