3AC6-D8 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

3AC6-D8

Honeywell

MICRO SWITCH™ Door Switches: AC Series, Single Pole Double Throw (SPDT), 15.1 A 125/250 Vac, 3 Position (Push-Momentary, Pull-Maintained), 6-32 UNC Threaded Steel Rod Actuator, Supplied with V3 Basic Switch, 4,75 mm x 0,50 mm [0.187 in x 0.020 in] Quick Connect Termination .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
3AC6-D8
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
10
Type:
Door Interlock
Actuator Style:
Rod
Pole Throw Configuration:
SPDT
Maximum Current Rating:
15.1@250VAC A
Terminal Type:
Quick Connect
Operating Temperature:
-18 to 82 °C
IP Rating:
N/A
Dimension:
52.32 x 12.7 x 45.97 mm
Switch Configuration:
N.O./N.C.
Body Orientation:
Straight
The HONEYWELL 3AC6-D8 is a MICRO SWITCH Door Switch from the AC Series, featuring a Single Pole Double Throw (SPDT) configuration with a 15.1 A 125/250 Vac rating. This switch offers 3 positions: Push-Momentary, Pull-Maintained, and comes with a durable 6-32 UNC Threaded Steel Rod Actuator. It is equipped with a V3 Basic Switch and features 4.75 mm x 0.50 mm [0.187 in x 0.020 in] Quick Connect Termination for easy installation. Ideal for various industrial applications, this reliable door switch ensures smooth and efficient operation.
Características destacadas del producto:
  • Automatically cuts power when service door or drawer is opened
  • Choice of momentary, maintained or pull-to-cheat actuation
  • Versatile mounting bracket for side or end mounting
  • Current rating ranges from 5 A to 25 A
  • Available with one or two SPDT switches
  • UL recognized versions available
  • Choice of termination
Aplicaciones potenciales:
<ul><li>Appliances</li><li>Vending machines</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li></ul>
Palabras clave de búsqueda:
3AC6D8
EN STOCK: 51
Puede enviar inmediatamente
MOQ para cantidad agotada:
13
Plazo de entrega de fábrica
21 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$240.97
$240.97
5
$233.53
$1,167.65
10
$231.22
$2,312.20
13
$230.64
$2,998.32
25
$230.06
$5,751.50
38
$229.49
$8,720.62
50 +
$228.92
$11,446.00
