3MN1 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

3MN1

Honeywell

MICRO SWITCH™ Basic Switches: MN Series, Double Pole Double Throw (DPDT), 15 A at 480 Vac, Pin Plunger Actuator, 3,34 N - 5,56 N [12 - 20 oz] Operating Force, Screw Termination .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
3MN1
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
200
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Pin Plunger
Contact Rating @ Voltage:
745.7@UL A
Maximum Movement Differential:
0.64 mm
Operating Force:
5.56 N
Termination Style:
Screw
Dimension:
63.5 x 17.15 x 34.16 mm
Body Orientation:
Straight
IP Rating:
N/A
<p>Snap action switches are short contact sensitive switches with the ability to respond quickly to small movements. This plunger switch is mostly used in industrial equipment's, presses and machine tools for its long mechanical life.</p><p>3MN11 Snap Action Switch from Honeywell is designed with arc-resistant plastic. The motor handling capacity of this Honeywell switch is 746 W [1 hp] at 240 Vac. The double-break circuitry and the space between the terminals reduces possibility of any short circuiting in the machine tools or industrial equipment's they are used in.</p>
Características destacadas del producto:
  • Arc-resistant plastic
  • Double-break circuitry
  • Power load switching capability to 15 A at 600 Vac
  • Long mechanical life to 10,000,000 cycles at 95% survival
  • Space between terminals reduces possibility of shorting
  • Motor handling capacity of 746 W [1 hp] at 240 Vac
Aplicaciones potenciales:
<ul><li>Machine Tools</li><li>Presses </li><li>Industrial equipment</li></ul>
Palabras clave de búsqueda:
3MN1
EN STOCK: 474
Puede enviar inmediatamente
MOQ para cantidad agotada:
50
Plazo de entrega de fábrica
9 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$87.22
$87.22
10
$85.23
$852.30
25
$85.02
$2,125.50
50
$84.80
$4,240.00
100
$84.59
$8,459.00
150
$84.38
$12,657.00
200 +
$84.17
$16,834.00
Haga clic para obtener una cotización
