4SX19-T by honeywell
Imagen de referencia - consulte las especificaciones del fabricante
FICHA TÉCNICA

4SX19-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 7 A 250 Vac, 1,39 N [5.0 oz] Maximum Operating Force, Pin Plunger Actuator, Special Characteristics Apply, Single Turret Solder Termination, High Temperature Construction 204 °C [400 °F], 4,83 mm [0.19 in] Mounting Centers, UL, CE, CSA, ENEC .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad
Atributo del producto
Valor del atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
4SX19-T
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Empaque estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precio y disponibilidad.
1
Montaje:
Through Hole
Configuración de Polos y Vías:
SPDT
Configuración del Interruptor:
N.O./N.C.
Material/Estilo del Actuador:
Plastic/Plunger
Capacidad de Contacto @ Tensión:
7 A
Diferencial de movimiento máximo:
0.05 mm
Fuerza de operación:
1.39 N
Estilo de Terminación:
Solder
Dimensión:
12.7 x 5.08 x 12.7 mm
Orientación del Cuerpo:
Straight
Grado de Protección IP:
N/A
The HONEYWELL part 4SX19-T is a MICRO SWITCH™ Subminiature Basic Switch that is part of the SX Series. It features a Single Pole Double Throw (SPDT) configuration, allowing for versatile circuit control. With a maximum operating force of 1.39 N [5.0 oz], this switch offers reliable and precise actuation. The pin plunger actuator is ideal for applications requiring a quick and responsive touch. The switch is equipped with special characteristics that make it suitable for various industrial and commercial applications. It features a single turret solder termination for convenient and secure electrical connections. Constructed with high-temperature materials, this switch can withstand temperatures up to 204 °C [400 °F]. With 4.83 mm [0.19 in] mounting centers, it offers easy installation and flexibility in positioning. Additionally, the switch is UL, CE, CSA, and ENEC certified, ensuring high-quality and compliance with international safety standards.
Características destacadas:
  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of operating characteristics
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 7 A)
  • MIL-PFR-8805 qualified listings available
Aplicaciones potenciales:
<ul><li>Aerospace</li><li>Appliances</li><li>Vending machines</li><li>Timing devices</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Palabras clave de búsqueda:
4SX19T
EN STOCK: 887
Puede enviar inmediatamente
Plazo de entrega de fábrica
5 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
1
$62.42
$62.42
5
$61.70
$308.50
10
$46.09
$460.90
25
$43.35
$1,083.75
50
$41.81
$2,090.50
100
$37.81
$3,781.00
250 +
$37.72
$9,430.00
