914CE19-3 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

914CE19-3

Honeywell

MICRO SWITCH™ Medium-Duty Limit Switches: 914CE Series Miniature Enclosed Switch, Top Adjustable Pin Plunger Actuator, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, 3 ft UL Cable .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
914CE19-3
RoHS:
Yes
HTS:
8536509055
COO:
GB
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1
Type:
Compact Precision
Actuator Style:
Adjustable Top Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
22.24 N
Dimension:
40 x 16 x 75.36 mm
Maximum Current Rating:
5@250VAC@(CE/cULus) A
Terminal Type:
Wire Lead
NEMA Standard as Enclosure Rating:
1, 2, 3, 3R, 4, 6, 6P, 13
Body Orientation:
Straight
<p>Limit Switches are generally used to control machinery in industrial applications. They act as a safety interlock and can be used to establish or disrupt electrical connections. The 914CE series compact enclosed switches incorporate fluorocarbon diaphragm sealing to provide reliable protection. The cable or connector and basic switch terminals are encapsulated in an epoxy compound, offering superior resistance in harsh environments. These limit switches are used in processing equipment, textile machinery, machine tools, robotics, packaging equipment, farm machinery, commercial laundry equipment, printing trade machinery and vehicles.</p><p>914CE19-3 Limit Switch from Honeywell comes with gang mounting capability, wide selection of actuators and zinc die-cast housing material. This miniature limit switch offers side and bottom exit cable/connector.</p>
Características destacadas del producto:
  • Compact construction
  • Enclosed switch
  • Zinc die-cast housing
  • Cable length variations
  • Gang mounting capability
  • Pre-wired or connector versions
  • Simple two-screw mounting
  • Low temperature variants
  • Side and bottom exit cable/connectors
  • Wide choice of actuators
  • Fluorocarbon sealing (standard)
  • Agency approvals and standards from UL, CSA, CE
Palabras clave de búsqueda:
914CE193
EN STOCK: 4
Puede enviar inmediatamente
A la orden:
10   puede enviar 6/22/26
Plazo de entrega de fábrica
12 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$214.85
$214.85
5
$210.65
$1,053.25
10
$201.00
$2,010.00
20
$199.99
$3,999.80
50
$198.99
$9,949.50
100 +
$198.00
$19,800.00
