BZ-2RDS725551-A2 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

BZ-2RDS725551-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 1 A 125 Vac, ENEC 1 A 250 Vac, Gold Alloy Contacts, 7,11 mm [0.280 in] Diameter Hardened Steel Additional Overtravel Plunger with Elastomer Plunger Seal Secured to Components by External Banding and Spring Retaining Ring, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
BZ-2RDS725551-A2
RoHS:
Yes
HTS:
8536501109
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Low Overtravel Plunger
Contact Rating @ Voltage:
1@125VAC@UL A
Maximum Movement Differential:
0.06 mm
Operating Force:
5.28 N
Termination Style:
Screw
Dimension:
49.3mm x 17.45mm x 39.12mm
Body Orientation:
Straight
IP Rating:
IP64
MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 1 A 125 Vac, ENEC 1 A 250 Vac, Gold Alloy Contacts, 7,11 mm [0.280 in] Diameter Hardened Steel Additional Overtravel Plunger with Elastomer Plunger Seal Secured to Components by External Banding and Spring Retaining Ring, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC
Características destacadas del producto:
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Choice of actuation, termination and operating characteristics
Aplicaciones potenciales:
<ul><li>Irrigation systems</li><li>Semi-trailer trucks</li><li>Timing devices</li><li>Office equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Palabras clave de búsqueda:
BZ2RDS725551A2
EN STOCK: 51
Puede enviar inmediatamente
MOQ para cantidad agotada:
50
Plazo de entrega de fábrica
19 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$83.59
$83.59
10
$83.38
$833.80
25
$83.17
$2,079.25
50
$82.96
$4,148.00
100
$43.92
$4,392.00
150
$30.91
$4,636.50
200 +
$30.29
$6,058.00
Suppliers Standard Package
