BZ-2RW80196-A2 by honeywell
Imagen de referencia - consulte las especificaciones del fabricante
FICHA TÉCNICA

BZ-2RW80196-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, 48,3 mm [1.90 in] Simulated Roller Lever Actuator, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad
Atributo del producto
Valor del atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
BZ-2RW80196-A2
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
50
Montaje:
Through Hole
Configuración de Polos y Vías:
SPDT
Configuración del Interruptor:
N.O./N.C.
Material/Estilo del Actuador:
Simulated Roller Lever
Capacidad de Contacto @ Tensión:
186.42 A
Diferencial de movimiento máximo:
1.02 mm
Fuerza de operación:
0.97 N
Estilo de Terminación:
Screw
Dimensión:
59.54mm x 17.45mm x 44.86 mm
Orientación del Cuerpo:
Straight
Grado de Protección IP:
N/A
<p>BZ-2RW80196-A2 Snap Action Switch from Honeywell comes with a low operating force and has a current rating of 15 A. Elongated mounting hole of this switch provides easier and accurate mounting. It also comes with screw termination, simulated roller lever actuator and silver contacts. This lever switch has a long mechanical life up to 20,000,000 cycles at 95% survival.</p> <p>Snap Action Switches are devices that are used to open or close an electrical circuit at a rapid speed. They are also known as micro switches. Honeywell Snap Action Switch BZ-2RW80196-A2 is widely used in various applications such as irrigation systems, semi-trailer trucks, timing devices, office equipment, test instruments, medical or dental equipment, HVAC equipment, manually operated devices, and valves.</p>
Características destacadas:
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Elongated mounting hole for easier and accurate mounting
  • Simulated roller lever actuator
  • Current rating ranges from 15 A to 25 A
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Choice of actuation, termination and operating characteristics
  • Operating temperature range: -55 °C to 85 °C
Palabras clave de búsqueda:
BZ2RW80196A2
EN STOCK: 323
Puede enviar inmediatamente
Plazo de entrega de fábrica
12 Semanas
Precio (USD)
Cantidad
Precio unitario
Precio total
1
$49.32
$49.32
5
$34.64
$173.20
10
$32.55
$325.50
25
$31.68
$792.00
50
$30.52
$1,526.00
100
$30.37
$3,037.00
250 +
$30.29
$7,572.50
Haga clic para solicitar una cotización
