SSCEB31C by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

SSCEB31C

Honeywell

MICRO SWITCH™ Medium-Duty Limit Switches: SSCE Series Miniature Enclosed Switch, Top Roller Parallel Plunger; 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Designed for Europe and Asia Pacific, Bottom Exit, 3 m Cable .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
SSCEB31C
RoHS:
Yes
HTS:
8536509065
COO:
GB
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1
Type:
Miniature
Actuator Style:
Top Roller Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
11.8 N
Dimension:
40 x 16 x 67 mm
Maximum Current Rating:
N/A
Terminal Type:
Wire Lead
NEMA Standard as Enclosure Rating:
1, 3, 6, 6P, 13
Body Orientation:
Straight
The HONEYWELL SSCEB31C is a MICRO SWITCHâ„¢ Medium-Duty Limit Switch from the SSCE Series, featuring a miniature enclosed design with a top roller parallel plunger. This switch is a single pole double throw (SPDT) with 1 normally closed and 1 normally open contact for versatile usage. Designed specifically for Europe and Asia Pacific markets, this limit switch has a bottom exit and comes with a 3-meter cable for convenient installation and connection.
Características destacadas del producto:
  • Fully sealed - capable of working when submerged
  • Compact construction
  • Rugged zinc die-cast housing
  • Pre-wired or connector versions
  • Variable length PUR cable
  • Side and bottom exit cable/connector
  • Simple two-screw mounting
  • Gang mounting capability
  • Wide selection of actuators
  • IP66/67, IP68 sealing
Palabras clave de búsqueda:
SSCEB31C
EN STOCK: 0
A la orden:
25   puede enviar 6/10/26
Plazo de entrega de fábrica
17 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$317.46
$317.46
5
$271.60
$1,358.00
10
$239.09
$2,390.90
20
$235.41
$4,708.20
50
$231.72
$11,586.00
100 +
$231.14
$23,114.00
Haga clic para obtener una cotización
