V7-1C17E9-207 by honeywell
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

V7-1C17E9-207

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 15.1 A 125, 250, or 277 Vac, 34 mm [1.34 in] Roller Lever Actuator, 86 g [3.03 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA .. Ver descripción completa

Cumple con RoHS
Tray embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
V7-1C17E9-207
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
200
Tipo de paquete:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Roller Lever
Contact Rating @ Voltage:
15.1@277VAC A
Maximum Movement Differential:
0.64 mm
Operating Force:
0.84 N
Termination Style:
Quick Connect
Body Orientation:
Straight
IP Rating:
N/A
<p>Snap Action Switches, also known as micro switches, are switch devices that are used to open or close an electrical circuit at a rapid speed. These highly sensitive switches are very often used in appliances, vending machines, timing devices, office equipment, test instruments, HVAC systems, manually operated devices, valves, gaming equipment, and pressure switches.</p><p>V7-1C17E9-207 Snap Action Switch from Honeywell is a miniature-type, basic micro switch. With an operating temperature range between -40 °C to 82 °C [-40 °F to 180 °F], it delivers reliable performance even in harsh environments. Specifically designed for 100K operations at a full load, this Honeywell Switch is ideal for higher cost-of-failure applications. The current rating of this Honeywell Snap Action Switch ranges from 0.1 A to 25 A.</p>
Características destacadas del producto:
  • Current rating ranges from 0.1 A to 25 A
  • Best suited for higher cost-of-failure applications
  • UL/CSA and ENEC approvals
  • Designed for 100K operations at a full load or 10M for mechanical life
  • World-wide package size acceptance
Aplicaciones potenciales:
<ul><li>Appliances</li><li>Vending machines</li><li>Timing devices</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li><li>Gaming equipment</li><li>Pressure switches</li></ul>
Palabras clave de búsqueda:
V71C17E9207
EN STOCK: 5.870
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
11 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$4.88
$24.40
50
$3.74
$187.00
200
$3.66
$732.00
400
$3.65
$1,460.00
600
$3.52
$2,112.00
1.000
$3.51
$3,510.00
2.600
$3.50
$9,100.00
5.000 +
$3.49
$17,450.00
Suppliers Standard Package
