HLG-320H-12B by mean well
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

HLG-320H-12B

MEAN WELL

AC/DC 320W LED Power Supply - Output Voltage 12VDC at 22A - Constant Current/Constant Voltage – Input from 90 to 305VAC or 127 to 431VDC - Dimming with 1-10VDC PWM resistance. .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
MEAN WELL
Nº de pieza:
HLG-320H-12B
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed, Dimmable
Dimming:
1 to 10 Vdc/PWM/Resistance
Maximum Output Power:
264 W
Output Voltage Range:
6.0 to 12.0 Vdc
Maximum Output Current:
22,000 mA (22.0 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-320H
HLG-320H-12B is a 320W AC/DC LED driver featuring a dual mode constant voltage and constant current output. This power supply operates from 90 to 305VAC or 127 to 431VDC. Voltage output is adjustable from 10.8 to 13.5VDC and current output adjustable from 11 to 22A. Thanks to the high efficiency up to 91%, it is able of operating from -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-320H-12B has a typical lifetime of 62000 hours and a 7 year factory warranty.
Palabras clave de búsqueda:
HLG320H12B
EN STOCK: 50
Puede enviar inmediatamente
Plazo de entrega de fábrica
16 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
1
$99.40
$99.40
5
$94.70
$473.50
10
$90.50
$905.00
20 +
$87.90
$1,758.00
