NC3FD-L-1
NEUTRIKDL Series - 3 pole female receptacle - solder cups - Nickel housing - silver contacts Universal D-size metal body XLR panel mount series. UL recognized component. .. Ver descripción completa
Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
NEUTRIK
Nº de pieza:
NC3FD-L-1
RoHS:
Yes
HTS:
8536694040.00
COO:
HU
ECCN:
EAR99
Paquete estándar del proveedor
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Straight
Mounting:
Panel Mount
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
Silver over Nickel
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
The NC3FD-L-1 is 3 pole female receptacle, solder cups, Nickel housing, silver contacts The NC3FD-L-1 has rated voltage of < 50 V and rated current per contact of 16 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series. UL recognized component.
Características destacadas del producto:
- Robust "D" metal shell
- Standardized D sized 24 mm panel cutout
- Solder cups on 3 - 7 pole version
Palabras clave de búsqueda:
NC3FDL1
EN STOCK:
2.124
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
3 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$5.21
$26.05
50
$4.80
$240.00
100
$4.03
$403.00
300
$3.97
$1,191.00
500
$3.95
$1,975.00
1.000
$3.94
$3,940.00
2.500
$3.93
$9,825.00
5.000
+
$3.92
$19,600.00
Guías de productos
FICHA TÉCNICA
Learn more about Neutrik Solutions for Medical Applications
Product Changes
Product Change Notification
