NC3MD-H by neutrik
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

NC3MD-H

NEUTRIK

D Series - 3 pole male receptacle - horizontal PCB mount - Nickel housing - silver contacts Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component. .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
NEUTRIK
Nº de pieza:
NC3MD-H
RoHS:
Yes
HTS:
8536694040.00
COO:
HU
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
Silver over Nickel
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
The NC3MD-H is 3 pole male receptacle, horizontal PCB mount, Nickel housing, silver contacts The NC3MD-H has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component.
Características destacadas del producto:
  • D-shape metal shell
  • Optimal RF protection using 3 shield contacts
  • Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
  • Front or rear panel mount
Palabras clave de búsqueda:
NC3MDH
EN STOCK: 1.362
Puede enviar inmediatamente
Cantidad mínima de pedido:
5
Plazo de entrega de fábrica
3 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
5
$6.73
$33.65
25
$6.13
$153.25
50
$6.07
$303.50
100
$6.01
$601.00
300
$5.99
$1,797.00
500
$5.98
$2,990.00
1.000
$5.96
$5,960.00
2.500 +
$5.95
$14,875.00
