NC6FXX-B by neutrik
La imagen es representativa - ver especificaciones del fabricante
FICHA TÉCNICA

NC6FXX-B

NEUTRIK

XX Series - 6 pole female cable connector with black metal housing and gold contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable - .. Ver descripción completa

Cumple con RoHS
embalaje
Accesorios
Accesorios
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Atributo del producto
Valor de atributo Seleccionar atributo
Productos Encontrados: 0
Proveedor:
NEUTRIK
Nº de pieza:
NC6FXX-B
RoHS:
Yes
HTS:
8536694020.00
COO:
LI
ECCN:
EAR99
Paquete estándar del proveedor Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
25
Type:
XLR Connector3389
Gender:
F3371
Body Orientation:
Straight3367
Mounting:
Cable Mount3378
Housing Material:
N/A
Number of Contacts:
6
Contact Plating:
Gold3369
Termination Method:
N/A
Operating Temperature:
N/A
The NC6FXX from Neutrik is a 6 pole female XLR cable connector with sleek and ergonomic design. This reliable and easier to assemble connector provides improved contact integrity and cable strain relief. The valuable and handy XLR male connector has improved chuck type strain relief which provides higher pull-out force and makes assembly easier and faster. Boot with polyurethane gland gives high protection to cable bending stresses. The coloured rings and boots available for coding or identification. The cable outer diameter ranges from 3.5mm to 8mm. Unique cage design of female contact provides low contact resistance and high integrity. It incorporates solder barrier to prevent solder running into the contact mating area. Female connector with improved solid metal latch is larger and easier to handle. This connector also has additional ground spring contacts for better shell ground continuity and internal thread on shell is well protected against any damage.
Palabras clave de búsqueda:
NC6FXXB
EN STOCK: 124
Puede enviar inmediatamente
Cantidad mínima de pedido:
25
Múltiple:
25
Plazo de entrega de fábrica
3 Semanas
Precio (USD)
Cantidad
Precio por unidad
Precio Ext.
25
$17.12
$428.00
50
$16.73
$836.50
100
$16.17
$1,617.00
250
$14.96
$3,740.00
500
$14.92
$7,460.00
1.000
$14.88
$14,880.00
2.500 +
$14.84
$37,100.00
